HYDRO 4 V2

Wall-hung hydronic fancoil
The customer service provides
prompt answers within 24 hours.
New modern design
Standard thermoregulation
Heating and cooling

Technical data HYDRO 4 V2

Code 3.033626
C.H. Heat Output max speed 45/40°C 4,30
Cooling Heat Output max speed 7/12°C kW 3,81
Dimensions (HxWxD) mm 290 x 915 x 230
Flow rate 7/12°C l/h 670
Empty appliance weight kg 12,7

Technical data HYDRO 4 V2

Code 3.033626
C.H. Heat Output max speed 45/40°C 4,30
Cooling Heat Output max speed 7/12°C kW 3,81
Dimensions (HxWxD) mm 290 x 915 x 230
Flow rate 7/12°C l/h 670
Empty appliance weight kg 12,7

Gallery

They can be matched whit hybrid systems and heat pumps to complete Immergas offer so to deliver a comfortable temperature as wished (heating and cooling).

  • New Aesthetics;
  • Microprocessor control to ensure optimum comfort in the environment; management of all functions via LCD remote control supplied as standard
  • 3-way valve as standard with micro switch for transmitting the request to the hybrid system or the heat pump
  • Water heat exchanger with a large exchange surface with condensate drain and air vent valve;
  • Water probe and air probe supplied as standard
  • Horizontal and vertical directional wind deflectors
  • Adjustment in cooling and heating with 3 fan speeds plus Auto mode
  • Units made of ABS with high mechanical characteristics
  • Right piping as standard
...

Connection kit for HYDRO 3/4 left exit   Cod.3.029520

To be used in case of left side piping.
Arrangement box recessed for pipes is needed.



They can be matched whit hybrid systems and heat pumps to complete Immergas offer so to deliver a comfortable temperature as wished (heating and cooling).

  • New Aesthetics;
  • Microprocessor control to ensure optimum comfort in the environment; management of all functions via LCD remote control supplied as standard
  • 3-way valve as standard with micro switch for transmitting the request to the hybrid system or the heat pump
  • Water heat exchanger with a large exchange surface with condensate drain and air vent valve;
  • Water probe and air probe supplied as standard
  • Horizontal and vertical directional wind deflectors
  • Adjustment in cooling and heating with 3 fan speeds plus Auto mode
  • Units made of ABS with high mechanical characteristics
  • Right piping as standard
...

Connection kit for HYDRO 3/4 left exit   Cod.3.029520

To be used in case of left side piping.
Arrangement box recessed for pipes is needed.
